Figure 29: MC67 Battery Charging
2 Press the MC67 down to ensure it is seated properly.
A click indicates that the MC67 button release locking mechanism is enabled and the MC67 is locked in place.
Caution: Ensure the MC67 is fully inserted in the cradle. Lack of proper insertion may result in property
damage or personal injury. We are not responsible for any loss resulting from the use of the products while
driving.
Removing the MC67
Procedure:
1 Press the release levers on the cradle.
2 Pull the MC67 up and out of the cradle.
42 | Accessories
May 2015 | MN000116A02-A
