Installation
Install the vehicle mount on the surface of your vehicle that is reasonably flat and free of dirt and oil. Clean the
mounting surface with a glass cleaner and a clean cotton cloth. Install the vehicle mount on the windshield or other
flat car surface using the supplied mounting disc.
Assembly
Procedure:
1 Insert the vehicle holder’s cradle plate to the holes on the back of the cradle.
2 Push the cradle down until both parts are engaged.
Windshield Installation
Procedure:
1 Fix the suction cup mount to the selected area with the suction lever facing up.
Figure 37: Windshield Installation
Cradle Plate
Cradle
Suction Cup Mount
2 Flip the lever down to create a vacuum between the suction cup and the mounting surface.
3 Make sure that the suction bond is strong enough before proceeding to the next step.
4 Slide the MC67 into the cradle.
Accessories | 49
MN000116A02-A | May 2015
