Figure 96: RxLogger
RxLogger Configuration
RxLogger is built with an extensible plug-in architecture and comes packaged with a number of plugins already built-
in. The included plug-ins are described below. Touch Settings to open the configuration screen.
Figure 97: RxLogger Configuration Screen
Main Log Plug-in
The Main log presents a high level timeline view of the device health in an easy to read comma-separated values
(CSV) format. The log contains many of the key parameters of various subsystems and is meant to be used as a first
level triage that can potentially point to a range of specific detailed logs to look at. The two rightmost columns in the
CSV file allow the log modules and plug-ins to insert asynchronous event based messages into the log. This is useful
so that by looking at the CSV log you can see when snapshots have been created or when the tool has detected an
application to be unresponsive. It is also used to show power events such as AC/DC power transitions.
• Log Interval - Specifies the interval, in milliseconds, to poll the collected parameters and write the data to the
CSV log file.
• Log path - Specifies the base log path to store the CSV log file. The default to use the default external storage
directory which is queried from the Android system.
• Log base filename - The base filename to use for the CSV file before appending the index number of that
particular log file. For example, if the base filename is Resource and we are rotating through two log files, the
actual filename will be: Resource0.csvand Resource1.csv.
• Log file count - Specifies the number of files to rotate through. Each file is constrained by the Log max size
option.
• Log max size - Specifies the maximum size, in kilobytes, of each log file for the main CSV log.
132 | Application Deployment
May 2015 | MN000116A02-A
