Motorola MC67 Integrator Guide

Table 16: Data Capture Supported Symbologies
Item Description
1D Bar Codes Chinese 2 of 5, Code 128, Coupon Code, EAN-13, GS1 DataBar Expanded, GS1 DataBar
Limited, Korean 2 of 5, TLC39, UPCA, UPC/EAN Supplementals, Codabar, Code 39, Dis-
crete 2 of 5, GS1 DataBar, GS1 DataBar Expanded Stacked, Interleaved 2 of 5, Matrix 2 of
5, Trioptic 39, UPCE, Webcode, Code 11, Code 93, EAN-8, GS1 DataBar 14, ISBT 128,
MSI, UCC/EAN 128, UPCE1
2D Bar Codes Australian Postal, Composite AB, Dutch Postal, Maxi Code, PDF-417, UK Postal, Aztec,
Composite C, Japanese Postal, Micro PDF-417, QR Code, US Postnet, Canadian Postal, Da-
ta Matrix, Linked Aztec, microQR, US Planet, USPS 4-state (US4CB),
SE4500–SR Decode Zone
The figure below shows the decode zone for the SE4500-SR. Typical values appear. Table 17: SE4500-SR Decode
Distances on page 151 lists the typical distances for selected bar code densities. The minimum element width (or
“symbol density”) is the width in mils of the narrowest element (bar or space) in the symbol.
Note: Typical performance at 73°F (23°C) on high quality symbols in normal room light.
Figure 98: SE-4500SR Decode Zone
In.
cm
0
20 mil Code 39
Depth of Field
24.7
5
10 15 20
25
0
12.7 25.4
38.1
50.8
63.5
13 mil (100% UPC)
14.7
1.6
15.5
15 mil PDF417
0
cm
W
i
d
t
h
o
f
F
i
e
l
d
0
4.5
11.4
9
22.9
22.9
*
*
* Minimum distance determined by symbol length and scan angle.
9
11.4
in.
Note: Typical performance at 73˚F (23˚C)
on high quality symbols in normal room light.
Vcc = 3.3V
4.5
12.4
15 mil Data Matrix
2.8
10.1
10 mil PDF417
*
10.6
7.5 mil Code 39
*
6.67 mil PDF417
3.4
7.1
5 mil Code 39
2.1
7.5
150 | Technical Specifications
May 2015 | MN000116A02-A
