• USB Charging Cable
• Charge Only Cable
• Single Slot USB Cradle
• Four Slot Charge Only Cradle
• Four Slot Ethernet Cradle.
Charge batteries in temperatures from 0 °C to 40 °C (32 °F to 104 °F). Note that charging is intelligently controlled
by the MC67. To accomplish this, for small periods of time, the MC67 or accessory alternately enables and disables
battery charging to keep the battery at acceptable temperatures. The MC67 or accessory indicates when charging is
disabled due to abnormal temperatures via its LED.
Procedure:
1 To charge the main battery, connect the charging accessory to the appropriate power source.
2 Insert the MC67 into a cradle or attach to a cable. The MC67 turns on and begins charging. The Charging/Battery
Status LED blinks amber while charging, then turns solid amber when fully charged.
LED Charging Indicators
Table 1: LED Charging Indicators
Charging/Battery Status LED Indication
Off MC67 is not charging. MC67 is not inserted correctly in the cradle or
connected to a power source. Charger/cradle is not powered.
Slow Blinking Amber (1 blink every 2
seconds)
MC67 is charging.
Solid Amber Charging complete. Note: When the battery is initially inserted in the
MC67, the amber LED flashes once if the battery power is low or the
battery is not fully inserted.
Fast Blinking Amber (2 blinks/second)
Charging error, e.g.:
• Temperature is too low or too high.
• Charging has gone on too long without completion (typically eight
hours).
Powering On the MC67
Note: If during installation of the battery, the battery has significant charge, the MC67 turns on
automatically.
Procedure:
Press the Power button to turn on the MC67.
The splash screen displays for about a minute as the MC67 initializes its flash file system.
Replacing the Battery
Procedure:
1 If the MC67 is in a cradle, remove it before performing a Safe Battery Swap.
2 Unclip the handstrap.
3 Press and hold the Power button until the menu appears.
Getting Started | 19
MN000116A02-A | May 2015
