Figure 35: Cable Cup Locking Tabs
4 To remove, slide the two locking tab down and remove the cable from the MC67.
Charging the MC67
Insert the MC67 into a slot to begin charging. The MC67’s Charging/Battery Status LED shows the status of the
battery charging in the MC67.
The 3600 mAh battery fully charges in approximately six hours.
Charging Temperature
Charge batteries in temperatures from 0 °C to 40 °C (32 °F to 104 °F). Charging is intelligently controlled by the
MC67.
To accomplish this, for small periods of time, the MC67 alternately enables and disables battery charging to keep the
battery at acceptable temperatures. The MC67 indicates when charging is disabled due to abnormal temperatures via
its LED.
Accessories | 47
MN000116A02-A | May 2015
