Device Configuration 5 - 19
10. Select + Add Row as needed to populate the table with IP addresses or hostnames of adoption resources.
11. Select OK to save the changes made to the general profile configuration. Select Reset to revert to the last saved
configuration.
5.2.4 Profile Wired 802.1X Configuration
System Profile Configuration
802.1X provides administrators secure, identity based access control as another data protection option to utilize with a device
profile.
802.1X is an IEEE standard for media-level (Layer 2) access control, offering the capability to permit or deny network
connectivity based on the identity of the user or device.
1. Select the Configuration tab from the Web UI.
2. Select Devices.
3. Select System Profile from the options on left-hand side of the UI.
4. Select Wired 802.1x.
Figure 5-11 Profile Wired 802.1X screen
5. Set the following Wired 802.1x Settings:
Routing Level Use the spinner controller to set the routing level for the Virtual Controller link. The
default setting is 1.
IPSec Support Select to enable secure communication between the access point and wireless
controllers.
IPSec GW Use the drop-down menu to specify if the IPSec gateway resource is defined as a (non
DNS) IP address or a hostname. Once defined, provide the numerical IP or hostname. A
hostname cannot exceed 64 characters.
Force Select to enable the link to the adopting controller or the controller group to be created
even when not required.
Dot1x Authentication
Control
Select this option to globally enable 802.1x authentication for the selected device. This
setting is disabled by default.
Dot1x AAA Policy Use the drop-down menu to select an AAA policy to associate with wired 802.1x traffic. If
a suitable AAA policy does not exist, click the Create icon to create a new policy or the
Edit icon to modify an existing policy.
