13 - 52 WiNG 5.5 Access Point System Reference Guide
13.2.13 Captive Portal
RF Domain Statistics
A captive portal is guest access policy for providing guests temporary and restrictive access to the controller or service platform
managed wireless network. Captive portal authentication is used primarily for guest or visitor access to the network, but is
increasingly being used to provide authenticated access to private network resources when 802.1X EAP is not a viable option.
Captive portal authentication does not provide end-user data encryption, but it can be used with static WEP, WPA-PSK or
WPA2-PSK encryption.
To view the RF Domain captive portal statistics:
1. Select the Statistics menu from the Web UI.
2. Select a RF Domain from under the System node on the top, left-hand side, of the screen.
3. Select Captive Portal from the RF Domain menu.
Figure 13-30 RF Domain - Captive Portal
The screen displays the following Captive Portal data for requesting clients:
Client MAC Displays the MAC address of each listed client requesting captive portal access to the
controller or service platform managed network. This address can be selected to display
client information in greater detail.
Hostname Lists the administrator assigned hostname of the device requesting captive portal access
to network’s Rf Domain resources.
Client IP Displays the IP address of each listed client using its connected RF Domain member
access point for captive portal access.
Captive Portal Lists the name of the RF Domain captive portal currently being utilized by each listed
client.
Authentication Displays the authentication status of requesting clients attempting to connect to the
access point via the captive portal.
WLAN Displays the name of the WLAN the requesting client would use for interoperation with
the access point.
