13 - 128 WiNG 5.5 Access Point System Reference Guide
13.3.26.2 WIPS Events
WIPS
To view the WIPS events statistics:
1. Select the Statistics menu from the Web UI.
2. Select System from the navigation pane (on the left-hand side of the screen). Expand a RF Domain and select one of its
connected access points.
3. Select WIPS and expand the menu to reveal its sub menu items.
4. Select WIPS Events.
Figure 13-85 Access Point - WIPS Events screen
The WIPS Events screen provides the following:
Blacklisted Client Displays the MAC address of the unauthorized and blacklisted device intruding this access
point’s radio coverage area.
Time Blacklisted Displays the time when the client was blacklisted by this access point.
Total Time Displays the time the unauthorized (now blacklisted) device remained in this access point’s
WLAN.
Time Left Displays the time the blacklisted client remains on the list.
Refresh Select the Refresh button to update the statistics counters to their latest values.
Event Name Displays the name of the detected wireless intrusion event.
Reporting AP Displays the MAC address of the access point reporting the listed intrusion.
Originating Device Displays the MAC address of the intruding device.
Detector Radio Displays the number of the detecting access point radio.
Time Reported Displays the time when the intrusion event was detected.
Clear All Select the Clear All button to clear the screen of its current status and begin a new data
collection.
