12 - 6 WiNG 5.5 Access Point System Reference Guide
5. Select Export button to export the running configuration using the settings configured in the Export Config field.
6. To update the screen with the latest changes made to the running configuration, select the Refresh button located to the
bottom right of the screen.
12.1.1.2 Managing Startup Configuration
Managing Firmware and Configuration Files
Startup configuration is the configuration that will be loaded the next time the device is booted. To view and manage the
startup configuration:
1. Select a target device from the left-hand side of the UI.
Figure 12-6 Device Browser
2. Select the down arrow next to the device to view a set of operations that can be performed on the selected device.
Figure 12-7 Device Browser - Options for a device
3. Select Show Startup Config to display the Startup Configuration window.
Host Enter IP address or the hostname of the server used to export the running
configuration to. This option is not valid for local, cf, usb1, usb2, usb3 and usb4.
Path/File Specify the path to the folder to export the running configuration to. Enter the
complete relative path to the file on the server.
User Name Define the user name used to access either a FTP or SFTP server.
This field is only available if the selected protocol is ftp or sftp.
Password Specify the user account password to access the FTP or a SFTP server.
This field is only available if the selected protocol is ftp or sftp.
NOTE: Another way to export the running configuration to the device used to view the
configuration is to click in the area that displays the running configuration and use the
[ctrl]+a keyboard combination to select all the contents of the text area into the OS’s
clipboard memory. Open a text editor, paste the copied content and save the file.
