Operations 12 - 5
Figure 12-5 Operations - Manage Running Configuration
4. Use the Export Config field to configure the parameters required to export the running configuration to an external server.
Refer to the following to configure the export parameters:
Protocol Select the protocol used for exporting the running configuration. Available options
include:
• tftp
• ftp
• sftp
• http
•cf
•usb1
•usb2
•usb3
•usb4
Port Use the spinner control or manually enter the value to define the port used by the
protocol for exporting the running configuration. This option is not valid for cf, usb1,
usb2, usb3 and usb4.
