13 - 102 WiNG 5.5 Access Point System Reference Guide
correlation between each MAC address and its corresponding IP address. ARP provides the protocol rules for making this
correlation and providing address conversion in both directions.
To view an access point’s ARP statistics:
1. Select the Statistics menu from the Web UI.
2. Select System from the navigation pane (on the left-hand side of the screen). Expand a RF Domain and select one of its
connected access points.
3. Select Network and expand the menu to reveal its submenu items.
4. Select ARP Entries.
Figure 13-64 Access Point - Network ARP screen
The ARP Entries screen describes the following:
13.3.21.2 Route Entries
Network
The Route Entries screen displays the destination subnet, gateway, and interface for routing packets to a defined destination.
When an existing destination subnet does not meet the needs of the network, add a new destination subnet, subnet mask and
gateway.
To view route entries:
1. Select the Statistics menu from the Web UI.
2. Select System from the navigation pane (on the left-hand side of the screen). Expand a RF Domain and select one of its
connected access points.
IP Address Displays the IP address of the client resolved on behalf of the access point.
ARP MAC Address Displays the MAC address corresponding to the IP address being resolved.
Type Lists the type of ARP entry.
VLAN Displays the system assigned VLAN ID where an IP address was found.
Refresh Select the Refresh button to update the screen’s statistics counters to their latest values.
