Device Configuration 5 - 9
5.1.2.2 Network Group Alias
RF Domain Configuration
A network group alias is a set of configurations that consist of host and network configurations. Network configurations are
complete networks in the form 192.168.10.0/24 or IP address range in the form 192.168.10.10-192.168.10.20. Host
configuration is in the form of single IP address, 192.168.10.23.
A network group alias can contain multiple definitions for host, network, and IP address range. A maximum of eight (8) host
entries, eight (8) network entries and eight (8) IP addresses range entries can be configured inside a network group alias. A
maximum of 32 network group alias entries can be created.
A network group alias is used in IP firewall rules to substitute hosts, subnets and IP address ranges:
To edit or delete a network alias configuration:
1. Select Configuration tab from the Web user interface.
2. Select Devices.
3. Select RF Domain.
4. Select the Network Group Alias tab. The following screen displays:
Figure 5-4 RF Domain - Network Group Alias screen
Name Displays the administrator assigned name of the network group alias.
Host Displays all host aliases configured in this network group alias. Displays a blank column if no
host alias is defined.
Network Displays all network aliases configured in this network group alias. Displays a blank column if
no network alias is defined.
