Statistics 13 - 57
13.3.2 Device
Access Point Statistics
The Device screen displays basic information about the selected access point. Use this screen to gather version information,
such as the installed firmware image version, the boot image and upgrade status.
To view the device statistics:
1. Select the Statistics menu from the Web UI.
2. Select System from the navigation pane (on the left-hand side of the screen). Expand a RF Domain and select one of its
connected access points.
3. Select Device.
Figure 13-32 Access Point - Device screen
The System field displays the following:
Model Number Displays the model of the selected access point to help distinguish its exact SKU and country
of operation.
Serial Number Displays the numeric serial number set for the access point.
Version Displays the software (firmware) version on the access point.
Boot Partition Displays the boot partition type.
Fallback Enabled Displays whether this option is enabled. This method enables a user to store a known legacy
version and a new version in device memory. The user can test the new software, and use an
automatic fallback, which loads the old version on the access point if the new version fails.
Fallback Image
Triggered
Displays whether the fallback image was triggered. The fallback image is an old version of a
known and operational software stored in device memory. This allows a user to test a new
version of software. If the new version fails, the user can use the old version of the software.
