13 - 60 WiNG 5.5 Access Point System Reference Guide
13.3.3 Device Upgrade
Access Point Statistics
The Device Upgrade screen displays information about devices receiving updates and the devices used to provision them. Use
this screen to gather version data, install firmware images, boot an image and upgrade status.
To view the device upgrade statistics:
1. Select the Statistics menu from the Web UI.
2. Select System from the navigation pane (on the left-hand side of the screen). Expand a RF Domain and select one of its
connected access points.
3. Select Device Upgrade.
Figure 13-33 Access Point - Device Upgrade screen
The Device Upgrade screen displays the following
Refresh Select Refresh to update the statistics counters to their latest values.
Upgraded By Device Displays the device that performed the upgrade.
Type Displays the model of the access point. The updating access point must be of the same model
as the access point receiving the update.
Device Hostname Displays the administrator assigned hostname of the device receiving the update.
History ID Displays a unique timestamp for the upgrade event.
Last Update Status Displays the error status of the last upgrade operation.
Time Last Upgraded Displays the date and time of the last successful upgrade operation.
Retries Count Displays the number of retries made in an update operation.
State Displays the current state of the access point upgrade.
Clear History Select the Clear History button to clear the screen of its current status and begin a new data
collection.
