5 - 38 WiNG 5.5 Access Point System Reference Guide
14. Select OK to save the changes to the security configuration. Select Reset to revert to the last saved configuration.
15. Select the Spanning Tree tab.
Figure 5-22 Port Channels - Spanning Tree tab
16. Define the following PortFast parameters for the port channel’s MSTP configuration:
17. Set the following MSTP Configuration parameters for the port channel:
Enable PortFast PortFast reduces the time required for a port to complete a MSTP state change from
Blocked to Forward. PortFast must only be enabled on ports on the wireless controller
directly connected to a server/workstation and not another hub or controller. PortFast can
be left unconfigured on an access point.
Select this option to enable drop-down menus for both the Enable PortFast BPDU Filter
and Enable PortFast BPDU Guard options. This setting is disabled by default.
PortFast BPDU Filter Select Enable to invoke a BPDU filter for this PortFast enabled port channel. Enabling the
BPDU filter feature ensures this port channel does not transmit or receive any BPDUs. The
default setting is None.
PortFast BPDU Guard Select Enable to invoke a BPDU guard for this PortFast enabled port channel. Enabling the
BPDU Guard feature means this port will shutdown on receiving a BPDU. Thus, no BPDUs
are processed. The default setting is None.
Enable as Edge Port Select this option to define this port as an edge port. Using an edge (private) port, you
can isolate devices to prevent connectivity over this port channel. This setting is
disabled by default.
