31. Select the OK button located at the bottom right of the screen to save the changes to the Advanced Settings screen.
Select Reset to revert to the last saved configuration.
5.2.5.4.1 MCS Data Rates
 Access Point Radio Configuration
802.11n MCS rates are defined as follows both with and without short guard intervals (SGI):
Table 5.1 MCS-1Stream
MCS Index
Number of
Streams
20 MHz
No SGI
20 MHz
With SGI
40 MHz
No SGI
40MHz
With SGI
016.57.213.515
1 1 1314.42730
2 1 19.5 21.7 40.5 45
3 1 2628.95460
4 1 3943.48190
5 1 52 57.8 108 120
6 1 58.5 65 121.5 135
7 1 65 72.2 135 150
Table 5.2 MCS-2Stream
MCS Index
Number of
Streams
20 MHz
No SGI
20 MHz
With SGI
40 MHz
No SGI
40MHz
With SGI
0 2 1314.42730
1 2 2628.95460
2 2 3943.48190
3 2 52 57.8 108 120
4 2 78 86.7 162 180
5 2 104 115.6 216 240
6 2 117 130 243 270
7 2 130 144.4 270 300
Table 5.3 MCS-3Stream
MCS Index
Number of
Streams
20 MHz
No SGI
20 MHz
With SGI
40 MHz
No SGI
40MHz
With SGI
0 3 19.5 21.7 40.5 45
1 3 3943.38190
2 3 58.5 65 121.5 135
