5 - 52 WiNG 5.5 Access Point System Reference Guide
Figure 5-28 Profile Interface - WAN Backhaul screen
5. Refer to the WAN (3G) Backhaul configuration to specify the access point’s WAN card interface settings:
6. Define the following authentication parameters from within the Basic Settings field:
7. Use the NAT Direction field to specify the NAT direction used with the access point’s WAN card. Options include Inside,
Outside or None. The default is None.
WAN Interface Name Displays the WAN Interface name for the WAN 3G Backhaul card.
Enable WAN (3G) Select this option to enable 3G WAN card support on the access point. A supported 3G
card must be connected for this feature to work.
Username Provide username for authentication support by the cellular data carrier.
Password Provide password for authentication support by the cellular data carrier.
Access Point Name
(APN)
Enter the name of the cellular data provider if necessary. This setting is needed in areas
with multiple cellular data providers using the same protocols such as Europe, the Middle
East and Asia.
Authentication Type Use the drop-down menu to specify authentication type used by the cellular data provider.
Supported authentication options include None, PAP, CHAP, MSCHAP, and MSCHAP-v2.
