5 - 62 WiNG 5.5 Access Point System Reference Guide
Figure 5-32 Network - L2TPv3 screen - General tab
5. Set the following General Settings for an L2TPv3 profile configuration:
6. Select the L2TPv3 Tunnel tab.
Host Name Define a 64 character maximum hostname to specify the name of the host that’s sent
tunnel messages. Tunnel establishment involves exchanging 3 message types (SCCRQ,
SCCRP and SCCN) with the peer. Tunnel IDs and capabilities are exchanged during the
tunnel establishment with the host.
Router ID Set either the numeric IP address or the integer used as an identifier for tunnel AVP
messages. AVP messages assist in the identification of a tunnelled peer.
UDP Listen Port Select this option to set the port used for listening to incoming traffic. Select a port from
1,024 - 65,353.
Tunnel Bridging Select this option to enable or disable bridge packets between two tunnel end points. This
setting is disabled by default.
