5 - 64 WiNG 5.5 Access Point System Reference Guide
8. Either select Add to create a new L2TPv3 tunnel configuration, Edit to modify an existing tunnel configuration or Delete
to remove a tunnel from those available to this profile.
Figure 5-34 Network - L2TPv3 screen - Add T2TP Tunnel Configuration
9. If creating a new tunnel configuration, assign it a 31 character maximum Name.
10. Define the following Settings required for the L2TP tunnel configuration:
Local IP Address Enter the IP address assigned as the local tunnel end point address, not the interface IP
address. This IP is used as the tunnel source IP address. If this parameter is not specified,
the source IP address is chosen automatically based on the tunnel peer IP address. This
parameter is applicable when establishing the tunnel and responding to incoming tunnel
create requests.
