Device Configuration 5 - 73
6. Use the spinner controls within the 802.1p Priority field for each DSCP row to change its priority value.
7. Select the OK button located at the bottom right of the screen to save the changes. Select Reset to revert to the last saved
configuration.
802.1p Priority Assign a 802.1p priority as a 3-bit IP precedence value in the Type of Service field of the
IP header used to set the priority. The valid values for this field are 0-7. Up to 64 entries
are permitted. The priority values are:
• 0 – Best Effort
• 1 – Background
• 2 – Spare
• 3 – Excellent Effort
• 4 – Controlled Load
• 5 – Video
• 6 – Voice
• 7 – Network Control
