Device Configuration 5 - 75
Figure 5-40 Network - Spanning Tree screen
5. Set the following MSTP Configuration parameters:
MSTP Enable Select this option to enable MSTP for this profile. MSTP is disabled by default, so
enable this setting if requiring different (groups) of VLANs with the profile supported
network segment.
Max Hop Count Define the maximum number of hops the BPDU considers valid in the spanning tree
topology. The available range is from 7 -127. The default setting is 20.
MST Config Name Define a 64 character maximum name for the MST region to use as an identifier for the
configuration.
MST Revision Level Set a numeric revision value ID for MST configuration information. Set a value from
0 - 255. The default setting is 0.
Cisco MSTP
Interoperability
Select either the Enable or Disable radio buttons to enable/disable interoperability with
Cisco’s version of MSTP, which is incompatible with standard MSTP. This setting is
disabled by default.
