Device Configuration 5 - 117
Figure 5-69 Profile Security - Remote VPN Server tab (IKEv2 example)
29. Select either the IKEv1 or IKEv2 radio button to enforce peer key exchanges over the remote VPN server using either IKEv1
or IKEv2.
IKEv2 provides improvements from the original IKEv1 design (improved cryptographic mechanisms, NAT and firewall
traversal, attack resistance etc.) and is recommended in most deployments. The appearance of the screen differs depending
on the selected IKE mode.
30. Set the following IKEv1 or IKe v2 Settings:
Authentication Method Use the drop-down menu to specify the authentication method used to validate the
credentials of the remote VPN client. Options include Local (on board RADIUS resource
if supported) and RADIUS (designated external RADIUS resource). If selecting Local,
select the + Add Row button and specify a User Name and Password for authenticating
remote VPN client connections with the local RADIUS resource. The default setting is
Local. AP6511 and AP6521 model access points do not have a local RADIUS resource
and must use an external RADIUS server resource.
