Device Configuration 5 - 177
Figure 5-111 Device Overrides - Basic Configuration screen
5. Set the following Configuration settings for the target device:
6. Refer to the Device Overrides field to assess whether overrides have been applied to the device’s configuration. Use the
Clear Overrides button to clear all device overrides and reset the configuration to its default values.
7. Refer to the Set Clock field to update the system time.
System Name Provide the selected device a system name up to 64 characters in length. This is the
device name that appears within the RF Domain or Profile the access point supports and
is identified by.
Latitude Coordinate Optionally provide the latitude coordinate where the device is located. The valid value for
this field is in the range -90.0000 degrees to +90.0000 degrees. When provided, this
enables the device to be mapped on the geolocation map.
Longitude Coordinate Optionally provide the longitude coordinate where the device is located. The valid value
for this field is in the range -180.0000 degrees to +180.0000 degrees. When provided, this
enables the device to be mapped on the geolocation map.
Area Assign the access point an Area representative of the location the access point is
physically deployed. The name cannot exceed 64 characters. Assigning an area is helpful
when grouping access points in profiles, as access points in the same physical
deployment location may need to share specific configuration parameters in respect to
radio transmission and interference requirements specific to that location.
Floor Assign the target access point a building Floor name representative of the location the
access point was physically deployed. The name cannot exceed 64 characters. Assigning
a building floor name is helpful when grouping devices in profiles, as devices on the same
physical building floor may need to share specific configuration parameters in respect to
radio transmission and interference requirements specific to that location.
