5 - 230 WiNG 5.5 Access Point System Reference Guide
Figure 5-143 Device Overrides - Access Point Radio Advanced Settings tab
22. Refer to the Aggregate MAC Protocol Data Unit (A-MPDU) field to define or override how MAC service frames are
aggregated by the access point radio.
23. Use the Aggregate MAC Service Data Unit (A-MSDU) drop-down menu to set or override the supported A-MSDU mode.
Available modes include Receive Only and Transmit and Receive. Using Transmit and Receive, frames up to 4 KB can be
sent and received. The buffer limit is not configurable.
24. Set or override the following profile Aeroscout Properties for the selected access point radio.
A-MPDU Modes Use the drop-down menu to define the A-MPDU mode. Options include Transmit Only,
Receive Only, Transmit and Receive and None. The default value is Transmit and Receive.
Using the default value, long frames can be both sent and received (up to 64 KB). When
enabled, define either a transmit or receive limit (or both).
Minimum Gap Between
Frames
Use the drop-down menu to define the minimum gap between A-MPDU frames (in
microseconds). The default value is 4 microseconds.
Received Frame Size
Limit
If a support mode is enable allowing A-MPDU frames to be received, define an advertised
maximum limit for received A-MPDU aggregated frames. Options include 8191, 16383,
32767 or 65535 bytes. The default value is 65535 bytes.
Transmit Frame Size
Limit
Use the spinner control to set limit on transmitted A-MPDU aggregated frames. The
available range is from 0 - 65,535 bytes). The default value is 65535 bytes.
Forward Select to enable forwarding of Aeroscout packets
MAC to be forwarded Enter the MAC address that is incorporated in the Aeroscout packets that are forwarded.
