5 - 234 WiNG 5.5 Access Point System Reference Guide
When PPPoE client operation is enabled, it discovers an available server and establishes a PPPoE link for traffic slow. When a
wired WAN connection failure is detected, traffic flows through the WWAN interface in fail-over mode (if the WWAN network
is configured and available). When the PPPoE link becomes accessible again, traffic is redirected back through the access
point’s wired WAN link.
When the access point initiates a PPPoE session, it first performs a discovery to identify the Ethernet MAC address of the PPPoE
client and establish a PPPoE session ID. In discovery, the PPPoE client discovers a server to host the PPPoE connection.
To create a PPPoE point-to-point configuration:
1. Select Devices from the Configuration tab.
2. Select Device Overrides from the Device menu to expand it into sub menu options.
3. Select a target device from the device browser in the lower, left-hand, side of the UI.
4. Select Interface to expand its submenu items
5. Select PPPoE. The following screen displays:
NOTE: PPPoE is supported on AP6522, AP6522M, AP6532, AP6562, AP8132, AP8232,
AP7131, AP7181 and AP7161 models and is not available on AP6511 and AP6521 model
access points.
