5 - 238 WiNG 5.5 Access Point System Reference Guide
Figure 5-146 Device Overrides - Network DNS screen
6. Provide or override the default Domain Name used when resolving DNS names. The name cannot exceed 64 characters.
7. Set or override the following Domain Name System (DNS) settings:
8. Provide a list of up to three DNS servers to forward DNS queries if DNS resources are unavailable. The DNS name servers
are used to resolve IP addresses. Use the Clear link next to each DNS server to clear the DNS name server’s IP address from
the list.
9. Select OK to save the changes and overrides made to the DNS configuration. Select Reset to revert to the last saved
configuration.
5.4.5.4.2 Overriding an ARP Configuration
Overriding the Network Configuration
Address Resolution Protocol (ARP) is a protocol for mapping an IP address to a hardware MAC address. ARP provides protocol
rules for making this correlation and providing address conversion in both directions. This ARP assignment can be overridden
NOTE: A blue override icon (to the left of a parameter) defines the parameter as having
an override applied. To remove an override, go to the Basic Configuration screen’s Device
Overrides field and select Clear Overrides. This will remove all overrides from the
device.
Enable Domain Lookup Select this option to enable DNS on the access point. When enabled, human friendly
domain names can be converted into numerical IP destination addresses. The radio button
is selected by default.
Enable DNS Server
Forwarding
Select this option to enable the forwarding DNS queries to external DNS servers if a DNS
query cannot be processed by the access point’s own DNS resources. This feature is
disabled by default.
