5 - 248 WiNG 5.5 Access Point System Reference Guide
24. Select the + Add Row button to set the following:
25. Select OK to save the changes and overrides to the session configuration. Select Reset to revert to the last saved
configuration.
5.4.5.4.4 Overriding IGMP Snooping Configuration
Overriding the Network Configuration
Internet Group Management Protocol (IGMP) is a protocol to establish and maintain multicast group memberships to interested
members. Multicasting allows a computer on a network to send content to multiple computers who have registered to receive
the content. IGMP Snooping is the term for listening to IGMP traffic between an IGMP host and routers in the network to
maintain a map of the links that require multicast streams. Multicast traffic is filtered out for those links which do not require
them.
To configure IGMP Snooping:
1. Select the Configuration tab from the Web UI.
2. Select Device Overrides from the Device menu to expand it into sub menu options.
3. Select a target device from the device browser in the lower, left-hand, side of the UI.
4. Select Network to expand its sub menu options.
5. Select IGMP Snooping.
Encapsulation Select either IP or UDP as the peer encapsulation protocol. The default setting is IP. UDP
uses a simple transmission model without implicit handshakes.
UDP Port If UDP encapsulation is selected, use the spinner control to define the UDP encapsulation
port. This is the port where the L2TP service is running.
Source VLAN Define the VLAN range (1 - 4,094) to include in the tunnel. Tunnel session data includes
VLAN tagged frames.
Native VLAN Select this option to define the native VLAN that will not be tagged
Cookie Size Set the size of the cookie field within each L2TP data packet. Options include 0, 4 and 8.
The default setting is 0.
Value 1 Set the cookie value first word.
Value 2 Set the cookie value second word.
End Point Define whether the tunnel end point is local or remote.
