5 - 300 WiNG 5.5 Access Point System Reference Guide
20. Select Add to create a new Dynamic NAT configuration, Edit to modify or override an existing configuration or Delete to
permanently remove a configuration.
Figure 5-193 Device Overrides - Security - NAT - Source ACL List screen
21. Set or override the following to define the Dynamic NAT configuration:
Network Displays Inside or Outside NAT as the network direction for the dynamic NAT
configuration.
Interface Lists the VLAN (from 1 - 4094) used as the communication medium between the source
and destination points within the NAT configuration.
Overload Type Options include NAT Pool, One Global Address and Interface IP Address. Interface IP
Address is the default setting.
NAT Pool Displays the name of an existing NAT pool used with the dynamic NAT configuration.
Overload IP If One Global IP Address is selected as the Overload Type, define an IP address used as a
filter address for the IP ACL rule.
ACL Precedence Lists the administrator assigned priority set for the listed source list ACL. The lower the
value listed, the higher the priority assigned to this ACL rule.
Source List ACL Use the drop-down menu to select an ACL name to define the packet selection criteria for
NAT. NAT is applied only on packets which match a rule defined in the access-list. These
addresses (once translated) will not be exposed to the outside world when the translation
address is used to interact with the remote destination.
Network Select Inside or Outside NAT as the network direction for the dynamic NAT configuration.
Inside is the default setting.
ACL Precedence Set the priority (from 1 - 5000) for the source list ACL. The lower the value, the higher the
priority assigned to the ACL rule.
