5 - 322 WiNG 5.5 Access Point System Reference Guide
8. Click the Auto Channel Selection tab to configure the parameters for the Mesh Connex Auto Channel Selection policy.
The following screen displays:
Figure 5-209 Mesh Point Auto Channel Selection screen
9. By default, the Dynamic Root Selection screen displays.
This screen provides configuration for the 2.4 GHz and 5.0/4.9 GHz frequencies. Refer to the following for more information
on the Auto Channel Selection Dynamic Root Selection screen. These descriptions are common for configuring the 2.4 GHZ
and 5.0/4.9 GHz frequencies
Channel Width Configure the channel width that mesh point automatic channel scan should assign to the
selected radio. The available options are:
• Automatic – Indicates the channel width is calculated automatically. This is the
default value.
• 20 MHz – Indicates the width between two adjacent channels is 20 MHz.
• 40 MHz – Indicates the width between two adjacent channels is 40 MHz.
