6 - 64 WiNG 5.5 Access Point System Reference Guide
5. Either select Add to create a new radio QoS policy, or select an existing policy and select Edit to modify its configuration.
Figure 6-27 Radio QoS Policy screen - WMM tab
The Radio QoS Policy screen displays the WMM tab by default. Use the WMM tab to define the access category
configuration (CWMin, CWMax, AIFSN and TXOP values) in respect to the type of wireless data planned for this new or
updated radio QoS policy.
Implicit TPSEC A green check mark defines the policy as requiring wireless clients to send their traffic
specifications to an access point before they can transmit or receive data. If enabled, this
setting applies to just this radio’s QoS policy. When enabled, the access point simulates
the reception of frames for any traffic class by looking at the amount of traffic the client
is receiving and sending. If a client sends more traffic than configured for an admission
controlled traffic class, the traffic is forwarded at the priority of the next non admission
controlled traffic class. This applies to clients that do not send TPSEC frames only.
Voice A green check mark indicates voice prioritization QoS is enabled on the radio. A red X
indicates voice prioritization QoS is disabled on the radio.
Best Effort A green check mark indicates best effort QoS is enabled on the radio. A red X indicates
best effort QoS is disabled on the radio.
Video A green check mark indicates video prioritization QoS is enabled on the radio. A red X
indicates video prioritization QoS is disabled on the radio.
Background A green check mark indicates background prioritization QoS is enabled on the radio. A red
X indicates that background prioritization QoS is disabled on the radio.
