Wireless Configuration 6 - 95
Figure 6-44 Mesh QoS Policy - Rate Limit screen
6. Configure the following parameters in respect to the intended From Air Upstream Rate Limit, or traffic from the controller
to associated access point radios and their associated neighbor:
Mesh Tx Rate Limit Select this option to enable rate limiting for all data received from any mesh point in the
mesh. This feature is disabled by default.
Rate Define a receive rate limit from 50 - 1,000,000 kbps. This limit constitutes a threshold for
the maximum the number of packets transmitted or received over the mesh point (from all
access categories). Traffic that exceeds the defined rate is dropped and a log message is
generated. The default setting is 5000 kbps.
