Wireless Configuration 6 - 99
14. Select OK when completed to update this mesh QoS rate limit settings. Select Reset to revert the screen back to its last
saved configuration.
15. Select the Multimedia Optimizations tab.
Figure 6-45 Mesh QoS Policy - Multimedia Optimizations screen
16. Set the following Accelerated Multicast settings:
17. Select OK when completed to update the Mesh Multimedia Optimizations settings. Select Reset to revert to the last saved
configuration.
Voice Traffic Set a percentage value for voice traffic in the receive direction. This is a percentage of the
maximum burst size for voice traffic. Voice traffic exceeding the defined threshold is
dropped by the client and a log message is generated. The default threshold is 0%.0%
means no early random drops will occur.
Disable Multicast
Streaming
Select this option to disable Multicast Streaming on the mesh point.
Automatically Detect
Multicast Streams
Select this option tto have bridged multicast packets converted to unicast to provide
better overall airtime utilization and performance. The administrator can either have the
system automatically detect multicast streams and convert all detected multicast streams
to unicast, or specify which multicast streams are to be converted to unicast. When the
stream is converted and being queued up for transmission, there are a number of
classification mechanisms that can be applied to the stream and the administrator can
select what type of classification they would want.
Manually Configure
Multicast Addresses
Select this option and specify a list of multicast addresses and classifications. Packets are
accelerated when the destination addresses matches.
