Services Configuration 9 - 21
14. Define the following NetBIOS parameters required to complete the creation of the static binding configuration:
15. Refer to the Static Routes Installed on Clients field to set Destination IP and Gateway addresses enabling assignment
of static IP addresses without creating numerous host pools with manual bindings. This eliminates the need for a long
configuration file and reduces the space required in NVRAM to maintain address pools. Select the + Add Row button to
add individual destinations. Select the Delete icon to remove it from the list of those available.
16. Scroll down to the DHCP Option Values table to set Global DHCP options. A set of global DHCP options applies to all
clients, whereas a set of subnet options applies only to the clients on a specified subnet. If you configure the same option
in more than one set of options, the precedence of the option type decides which the DHCP server supports a client.
17. Select the + Add Row button to add individual options. Assign each a Global DHCP Option Name to help differentiate
it from others with similar configurations. At any time you can select the radio button of an existing option and select the
- Delete button to remove it from the list of those available.
18. Assign a Value to each option with codes in the range of 1 through 254. A vendor specific option definition only applies to
the vendor class for which it is defined.
19. Within the Network field, define one or group of DNS Servers to translate domain names to IP addresses. Up to 8 IP
addresses can be provided and translated. Select Alias to use a network alias with the DNS server configuration. For more
information see Alias on page 7-34.
Within the Network field, define one or more Default Routers to resolve routes to other parts of the network. Up to 8 IP
addresses can be provided for Default Routers. Select Alias to use a network alias with the default routers configuration.
For more information see Alias on page 7-34.
20. Select OK when completed to update the static bindings configuration. Select Reset to revert to the last saved
configuration.
21. Select the Advanced tab to define additional NetBIOS and Dynamic DNS parameters.
Client Name Provide the name of the client requesting DHCP Server support.
Enable Unicast Unicast packets are sent from one location to another location (there is just one sender,
and one receiver). Select this option to forward unicast messages to just a single device
within this network pool. This setting is disabled by default.
NetBIOS Node Type Set the NetBIOS Node Type used with this particular pool. The node can have one of the
following types:
• Broadcast - Uses broadcasting to query nodes on the network for the owner of a
NetBIOS name.
• Peer-to-Peer - Uses directed calls to communicate with a known NetBIOS name server
(such as a WINS server), for the IP address of a NetBIOS machine.
• Mixed - A mixed node using broadcast queries to find a node, and failing that, queries
a known p-node name server for the address.
• Hybrid - A combination of two or more nodes.
• Undefined - No node type is applied.
NetBIOS Servers
Specify a numerical IP address of a single or group of NetBIOS WINS servers available to
DHCP supported wireless clients. A maximum of 8 server IP addresses can be assigned.
Select Alias to use a network alias with the NetBIOS server configuration. For more
information see Alias on page 7-34.
