9 - 42 WiNG 5.5 Access Point System Reference Guide
Figure 9-24 RADIUS Server Policy screen - LDAP tab
27. Refer to the following to determine whether an LDAP server can be used as is, a server configuration requires creation or
modification or a configuration requires deletion:
28. Select Add to add a new LDAP server configuration, Edit to modify an existing LDAP server configuration or Delete to
remove a LDAP server from the list of those available.
Redundancy Displays whether the listed LDAP server IP address has been defined as a primary
or secondary server resource. Designating at least one secondary server is a good
practice to ensure RADIUS user information is available if a primary server were
to become unavailable.
IP Address Displays the IP address of the external LDAP server acting as the data source for
the access point’s local RADIUS server.
Port Lists the physical port used by the RADIUS server to secure a connection with the
remote LDAP server resource.
