9 - 44 WiNG 5.5 Access Point System Reference Guide
31. Set the following Attributes for LDAP groups to optimally refine group queries:
32. Select the OK button to save the changes to the LDAP server configuration. Select Reset to revert to the last saved
configuration.
Base DN Specify a distinguished name (DN) that establishes the base object for the search.
The base object is the point in the LDAP tree at which to start searching. LDAP
DNs begin with the most specific attribute (usually some sort of name), and
continue with progressively broader attributes, often ending with a country
attribute. The first component of the DN is referred to as the Relative
Distinguished Name (RDN). The RDN identifies an entry distinctly from any other
entries that have the same parent.
Bind Password Enter a valid password for the LDAP server. Select the Show check box to expose
the password’s actual character string. Leave the option unselected to display the
password as a string of asterisks (*). The password cannot 32 characters.
Password Attribute Enter the LDAP server password attribute. The password cannot exceed 64
characters.
Group Attribute LDAP systems have the facility to poll dynamic groups. In an LDAP dynamic
group, an administrator can specify search criteria. All users matching the
search criteria are considered a member of this dynamic group. Specify a group
attribute used by the LDAP server. An attribute could be a group name, group ID,
password or group membership name.
Group Filter Specify the group filters used by the LDAP server. The group filter is typically
used for security role-to-group assignments and specifies the property to look
up groups in the directory service.
Group Membership Attribute Specify the group member attribute sent to the LDAP server when
authenticating users.
