Operations 12 - 13
Figure 12-18 Device Browser - Options for a device
3. Select the Firmware Upgrade button to upgrade the device’s firmware.
Figure 12-19 Firmware Upgrade screen
4. Provide the following information to accurately define the location of the target device’s firmware file:
Protocol Select the protocol used for updating the firmware. Available options include:
• tftp
• ftp
• sftp
• http
•cf
•usb1
•usb2
•usb3
•usb4
•local
Port Use the spinner control or manually enter the value to define the port used by the
protocol for importing the firmware upgrade file. This option is not valid for local, cf,
usb1, usb2, usb3 and usb4.
Host Enter IP address or the hostname of the server used to import the firmware file. This
option is not valid for local, cf, usb1, usb2, usb3 and usb4. Use the drop-down to
select the type of host information. The host can be either an IP address or hostname.
