13 - 32 WiNG 5.5 Access Point System Reference Guide
Figure 13-21 RF Domain - Mesh Point Device Type screen
The Root field displays the Mesh ID and MAC Address of the configured root mesh points in the RF Domain.
8. The Non Root field displays the Mesh ID and MAC Address of all configured non-root mesh points in the RF Domain.
displays the Mesh ID and MAC Address of all configured non-root mesh points in the RF Domain.
9. The Mesh Point Details field on the bottom portion of the screen displays tabs for General, Path, Root, Multicast Path,
Neighbors, Security and Proxy. Refer to the following:
The General tab displays the following:
Mesh Point Name Displays the name of each configured mesh point in the RF Domain.
MAC Displays the MAC Address of each configured mesh point in the RF Domain.
Hostname Displays the administrator assigned hostname for each configured mesh point in the RF
Domain.
Configured As Root Indicates whether a mesh point is configured to act as a root device. (Yes/No).
Is Root A root mesh point is defined as a mesh point connected to the WAN and provides a wired
backhaul to the network. (Yes/No)
