13 - 34 WiNG 5.5 Access Point System Reference Guide
The Root tab displays the following:
The Multicast Path tab displays the following:
The Neighbors tab displays the following:
Sequence The sequence number also known as the destination sequence number. It is updated
whenever a mesh point receives new information about the sequence number from RREQ,
RREP, or RERR messages that may be received related to that destination.
Mesh Point Name Displays the name of each configured mesh point in the RF Domain.
Recommended Displays the root that is recommended by the mesh routing layer.
Root MPID The MP identifier is used to distinguish between other mesh points both on the same
device and on other devices. This is used by a user to setup the preferred root
configuration.
Next Hop IFID The IFID of the next hop. The IFID is the MAC Address on the destination device.
Radio Interface This indicates the interface that is used by the device to communicate with this neighbor.
The values are 2.4 and 5.0, indicating the frequency of the radio that is used to
communicate with the neighbor.
Bound Indicates whether the root is bound or unbound.
Metric Displays the computed path metric between the neighbor and their root mesh point.
Interface Bias This field lists any bias applied because of Preferred Root Interface Index.
Neighbor Bias This field lists any bias applied because of Preferred Root Next-Hop Neighbor IFID.
Root Bias This field lists any bias applied because of Preferred Root MPID.
Mesh Point Name Displays the name of each configured mesh point in the RF Domain.
Subscriber Name The identifier is used to distinguish between other mesh points both on the same device
and on other devices. This is used by a user to setup the preferred root configuration.
Subscriber MPID Lists the subscriber ID to distinguish between other mesh point neighbor devices in the
RF Domain.
Group Address Displays the MAC address used for the group in the mesh point.
Timeout The timeout interval in seconds. The interpretation of this value will vary depending on
the value of the state. If the state is Init or In Progress, the timeout duration has no
significance. If the state is Enabled, the timeout duration indicates the amount of time left
before the security validity check is initiated. If the state is Failed, the timeout duration is
the amount of time after which the system will retry.
Mesh Point Name Displays the name of each configured mesh point in the RF Domain.
Destination Addr Displays the MeshID (MAC Address) of each mesh point in the RF Domain.
