13 - 42 WiNG 5.5 Access Point System Reference Guide
The Proxy tab displays the following:
12.Select Device Data Transmit.
State Displays the Link State for each mesh point:
• Init - indicates the link has not been established or has expired.
• Enabled - indicates the link is available for communication.
• Failed - indicates the attempt to establish the link failed and cannot be retried yet.
• In Progress - indicates the link is being established but is not yet available.
Timeout Displays the maximum value in seconds that the link is allowed to stay in the In Progress
state before timing out.
Keep Alive Yes indicates the local MP acts as a supplicant to authenticate the link and not let it expire
(if possible). No indicates that the local MP does not need the link and will let it expire if
not maintained by the remote MP.
Mesh Point Name Displays the name of each configured mesh point in the RF Domain.
Destination Addr The destination is the endpoint of mesh path. It may be a MAC address or a mesh point ID.
Proxy Address Displays the MAC Address of the proxy used in the mesh point.
Age Displays the age of the proxy connection for each of the mesh points in the RF Domain.
Proxy Owner The owner (MPID) is used to distinguish the device that is the neighbor.
VLAN The VLAN ID used as a virtual interface with this proxy. A value of 4095 indicates that
there is no VLAN ID.
