4 - 6 WiNG 5.5 Access Point System Reference Guide
1. The Client RF Quality Index displays the following:
2. Periodically select Refresh (at the bottom of the screen) to update client RF quality.
Worst 5 Lists the worst 5 performing client radios connected to the access point. The RF Quality
Index measures the overall effectiveness of the RF environment as a percentage. Its a
function of the connect rate in both directions, as well as the retry rate and the error rate.
The quality is measured as:
• 0-20 – Very poor quality
• 20-40 – Poor quality
• 40-60 – Average quality
• 60-100 – Good quality
Client MAC Displays the factory encoded MAC address assigned to each connected radio listed. Use
this information to assist in the identification of poorly performing radios.
Retry Rate
Lists the number of retries attempted to re-connect with the listed radio.
