13 - 80 WiNG 5.5 Access Point System Reference Guide
Figure 13-48 Access Point - RTLS screen
The Access Point RTLS screen displays the following for Aeroscout tags:
Engine IP Lists the IP address of the Aeroscout locationing engine.
Engine Port Displays the port number of the Aeroscout engine.
Send Count Lists the number location determination packets sent by the locationing engine.
Recv Count Lists the number location determination packets received by the locationing engine.
Tag Reports Displays the number of tag reports received from locationing equipped radio devices
supporting RTLS.
Nacks Displays the number of Nack (no acknowledgement) frames received from RTLS supported
radio devices providing locationing services.
Acks Displays the number of Ack (acknowledgment) frames received from RTLS supported radio
devices providing locationing services.
Lbs Displays the number of location based service (LBS) frames received from RTLS supported
radio devices providing locationing services.
AP Status Provides the status of peer access points providing locationing assistance.
AP Notifications Displays a count of the number of notifications sent to access points that may be available to
provide RTLS support.
Send Errors Lists the number of send errors received by the RTLS initiating access point.
Error Message Count Displays a cumulative count of error messages received from RTLS enabled access point
radios.
