7 Functions and settings
Maschinenfabrik Reinhausen 2014 1133550953/00 EN TAPCON® 230 pro
You can recognize pulsed inputs from the preceding "P:". The note "Warn-
ing: P = pulsed inputs" is displayed on the screen.
You can assign one of the following functions to each of the digital inputs
(GPI 1...8):
Function Description
Off No function selected
Master/Follower Define master/follower mode.
Signal on: Master mode active
Signal off: Follower mode active.
Remote/Loc. Define remote/local mode.
Signal on: "Remote" operating
mode active.
Signal off: "Local" operating mode
active.
Blocking Block automatic regulation.
Quick Tap Activating quick reset (deactivating
delay time T1/T2)
MPS triggered
Motor running
Desired value 2
Input for MPS triggered feedback.
Input for Motor running feedback.
Activate desired value 2
Desired value 3 Activate desired value 3
Remote VL Activate setting the desired voltage
level remotely.
ParGroup1 Assign parallel operation group 1
ParGroup2 Assign parallel operation group 2
Blk U raise Block tap-change operations
(raise).
Blk U lower Block tap-change operations (low-
er).
P: Par. on Activate parallel operation.
P: S. mode
P: Master
P: Follower
Deactivate parallel operation (inde-
pendent).
Define master parallel mode.
Define follower parallel mode.
P: Syn. auto. Define "Automatic tap synchroniza-
tion" parallel mode.
P: Cir. curr. Define circulating reactive current
mode.
P: DV 1 Activate desired value 1
