PRODUCT DESCRIPTIONS
The MVP Control Panel
A typical MVP Control Panel consists of a single MVP Control Module and several Dual Chain Modules, one
for each two Chains in your System. In addition, you may have chosen to include Feature Modules in your
System, such as Watt Meters, and a Sound Pressure Meter with Speaker Equalizers (see pages 27-33).
The MVP Control Panel is the nerve center for all the functions of the Matrix System
®
. The user selects
individual components for a demonstration by entering the numbers which correspond to each component
using the MVP Control Panel buttons (or with the Remote Control Unit, see page 35).
Figure 4 – A Typical MVP Control Panel
