1310/1312 Switching Modules
The 1310 and the 1312 are combination low and high-level Switching Modules. On the right side of the
Modules are eight sets of high-level screw terminal connectors and on the left are eight sets of low-level RCA
connectors. The low-level side functions like the 1210/14 described previously. These Modules are designed
for applications requiring the switching of both low and high-level 2-Channel signals from the same
components (at the same Position).
If you have a display that was built by MTi, the high-level connectors on your 1310/1312 Switching
Modules have MTA connectors instead of screw terminals. All functions are identical.
A B C D E F G H LED +
-----------------LEDS---------------
ON
1 2 3 4
ON
A B
E
CD
F
GH
A
B
E
CD
F
GH
G
B
C
D
E
H
K
A
J
MATRIX MODEL 131
---------TURN-ON RELAYS-----
A B C D E F G H
+12
F
E
I
L
Figure 23 – 1312 Switching Module
