Matrix System
®
45
A. LED – Indicates that this Module is activated (active or bypassed).
B. DIP Switch – Using binary code, designates Component Selection Numbers for each
Switching Module (e.g. Module 2 in Front Deck Chain; Positions 8–15). See Appendix A for
Dip Switch setting instructions.
C. Control Cable Connectors – Supplied Control Cables are connected to these to connect
the first Switching Module in a Chain to the MVP Control Panel, then connect Module to
Module within a Chain.
D. Component Turn-on Relays – On the 1312, these relays switch power to selected
components. Not on the 1310.
E. Low-Level Bus Connectors – These connectors route signals from Module to Module
within a Chain and from Chain to Chain to form the signal bus.
F. Low-Level Connectors – Provides connection points for component inputs and outputs.
G. Component Turn-On Strip – Provides connection point for distribution of 12V DC power
to components when selected. Not on 1310.
H. LED Turn-On Strip – For non-lighted components (e.g., Speakers), LEDs can be mounted
nearby to indicate activation. When a Position is selected, a contact is made and the Turn-
On Strip provides power to the LEDs.
I. Input/Output Designation – Provides a space for labeling the Module with correct
information for each set of component connection points (e.g., DECK OUT LO, and DECK
OUT HI, for the low and high level outputs for the Deck Chain).
J. High-Level Connectors – Provides connection points for component high-level inputs and
outputs.
K. Module/Chain Name/Number – Provides space for labeling Module with its Chain name
and designation (e.g., DECK 2 = the second Module in the deck Chain).
L. High Level Bus Connectors – These connectors route signals from Module to Module
within a Chain and from Chain to Chain to form the signal bus.
