1820 S-VHS Switching Module
This Module enables the retailer to include Hi-Fi, Stereo S-VHS camcorders and VCRs in a Home Theater or
Video display. Standard VHS components can be switched with MTi’s Model 1210 or 1320 Low-level
Switching Modules. The left side of the 1820 is like other low-level Switching Modules. The right side
consists of component connectors and bus connectors for S-VHS Video Components.
This Module has eight S-VHS connectors and eight pairs of low-level RCA connectors, enabling it to switch
video and stereo audio signals to and/or from eight components per Module. These Modules may be
chained together to handle switching for up to 99 S-VHS components. The video signals can be routed to
any number and variety of monitors, and the audio signals can be routed to receivers and Speakers. Or
route the audio signal to a Matrix System controlled Home Theater display complete with Surround Sound
Processors and multiple Speaker pairs.
Figure 27 – 1820 Switching Module
