Matrix System
®
53
A. LED – Indicates that this Module is activated.
B. DIP Switch – Using binary code, designates Component Selection Numbers for each
Switching Module (e.g. Module 2 in VCR Chain; Positions 8–15). See DIP Switch setting
instructions, Appendix A.
C. Control Cable Connectors – Supplied Control Cables are connected to these to connect
the first Switching Module in a Chain to the MVP Control Panel, then connect Module to
Module within a Chain.
D. Low-Level Audio Bus Connectors – These connectors route signals from Module to
Module within a Chain and from Chain to Chain to form the signal bus.
E. Low-Level Connectors – Connection points for component low-level audio inputs and
outputs.
F. LED Turn-On Strip – For non-lighted components (e.g., Speakers), LEDs can be mounted
nearby to indicate activation. When a Position is selected, a contact is made and Turn-On
Strip sends power to LEDs.
G. Input/Output Designation – Provides a space for labeling Module with correct information
for each set of component connection points (e.g., S-VHS IN; and S-VHS OUT, for the
inputs and one set of outputs for the VCR Chain).
H. S-VHS Video Bus Connectors – These connectors route signals from Module to Module
within a Chain and from Chain to Chain to form the signal bus.
I. S-VHS Video Connectors – Connection points for S-VHS Video component inputs and
outputs.
J. Module/Chain Name/Number – Provides a space for labeling Module with its Chain name
and designation (e.g., S-VHS 2, for the second Module in the Video Chain).
