MTI Matrix System Series User Manual

Matrix System
®
87
1412
(9-16)
-2
1412
(1-8)
-1
1410
(1-8)
High Level Bus (Rear)
Rear Speaker #1
REAR SPKR
-1
High Level Out (L&R)
+12V Turn On
High Level Bus (L & R)
From +12V
Power Supply
Tape Deck #1
HEAD UNIT
From +12V
Power Supply
1410
(1-8)
+12V Power
High Level Bus
Low Level Bus
Legen
d
Signal Flow Low
Signal Flow High
High Level Bus (Front)
Front Speaker #1
FRT SPKR
-1
High Level Bus (L & R)
Figure 43 – Sample Autosound System I
