MTI Matrix System Series - Page 95

Matrix System
®
95
Figure 47 – Sample Autosound System III – Signal Flow
1440
(1-8)
1410
(1-8)
1410
(9-16)
-1
-2
FRT SPKR
SUB SPKR
1312
(0-7)
1312
(0-7)
1210
(1-8)
-1
-1
SUB AMP
REAR AMP
1410
(1-8)
-1
REAR SPKR
1442
(1-8)
FRONT AMP
Low Level Bus (Sub)
High Level Bus (Rear)
High Level Bus (Front)
+12V Turn On
From
+12V Power
Supply
Low Level Input (Front)
Bypass
Low level Bus (Front)
+12V Turn On
Bypass
High Level
Output (Front)
From
+12V Power
Supply
High Level
Output (Rear)
Low Level
Input (Rear)
Amplifier #1
High Level Output (Sub)
+12V Turn On
From +12V Power
Supply
Low Level Input (Sub)
Front Speaker #1
High Level Bus (L & R)
High Level Bus (Front)
Sub Speaker #1
Rear Speaker #1
High Level Bus (Rear)
High Level Bus (Sub)
